RV Electronics LCD Single Tank Water Level Indicator Gauge – Black (12V)
Product Overview
Get precise, continuous water level readings with the RV Electronics LCD Single Tank Water Level Indicator Gauge — a premium 12V monitoring solution for caravans, RVs, motorhomes, camper trailers, and boats.
This latest model features a coloured LCD analogue display with bright LED backlighting, giving you crystal-clear visibility of your tank levels at any time of day or night. The gauge shows five distinct water levels at a glance and can remain on continuously without draining your battery, drawing just 50 mA of current.
With a low-profile black design and simple side-mount sender probe installation, this gauge delivers accurate, reliable performance while blending seamlessly into any RV interior.
✅ Key Features
-
Clear LCD Display – Coloured analogue-style readout with LED backlighting for excellent visibility
-
Instant Level Check – Five-level display provides a live reading, no button press required
-
12V Powered, Low Draw – Just 50 mA current usage; safe for continuous operation
-
Built-In Power Switch – Easily turn the gauge off when your vehicle is not in use
-
Simple Installation – Side-mount probe attaches without tank removal
-
Reliable Performance – Probe uses five sensors with no moving parts for consistent accuracy
-
Universal Compatibility – Works with plastic or metal tanks
-
Retrofit-Ready – Compatible with existing RV Electronics sender probes
📦 What’s in the Box
-
1 × RV Electronics LCD Single Tank Water Level Indicator Gauge – Black
-
Mounting template & fitting instructions
🧰 Note: 1 × Sender Probe is required (sold separately). Choose from 2.5 m, 5 m, or 7.5 m lengths to suit your tank setup.
📊 Specifications
-
Brand / Model: RV Electronics LCD Single Tank Gauge
-
Display: Coloured LCD analogue with LED backlight (5-level display)
-
Power Supply: 12V DC
-
Current Draw: 50 mA (low power consumption)
-
Gauge Size (H × W × D): 108 × 108 × 20 mm
-
Tank Compatibility: Plastic & metal tanks
-
Sender Probe Options: 2.5 m / 5 m / 7.5 m (sold separately)
-
Probe Type: Side-mount, 5-sensor arm; no moving parts
🛠 Installation & Fitment
-
Mount the gauge using the 108 × 108 mm cut-out template.
-
Install the side-mount sender probe (no need to remove the tank).
-
Connect the probe lead to the gauge and wire the gauge to 12V DC.
-
Switch On for continuous monitoring or turn Off when not in use.
💡 Tip: The 2.5 m probe suits shorter installations, while 5 m and 7.5 m probes are ideal for longer cable runs or dual-compartment layouts.
🚐 Ideal For
-
Caravans
-
Motorhomes & RVs
-
Camper Trailers
-
Boats & Marine Tanks
Why Choose RV Electronics
✔ Trusted Australian brand for water level monitoring systems
✔ Bright, easy-to-read LCD display for real-time accuracy
✔ Low-draw 12V design — safe for continuous use
✔ Simple side-mount probe installation — no drilling from below
✔ Built to withstand Australia’s harsh touring conditions
Upgrade your caravan’s water monitoring system with the RV Electronics LCD Single Tank Gauge — the reliable, low-power, easy-to-read solution for accurate tank levels anywhere you travel.
