Description
FEATURES
- Double-chamber diaphragm pump
- Intermittent duty
- Self-priming
- Run-dry capability
- Fully automatic
- Industry-standard mounting pattern
- Quiet operation
- Smooth operation
- Ignition-protected
- Corrosion-resistant valves
- Low power draw
- Santoprene diaphragm
- Detailed installation and setup instructions
SPECIFICATIONS
- 12V Operation
- Up to 1.0 GPM (3.7LPM)
- 40 PSI Pressure Setting
- Amps 1.6A (Max 4.0A)
- Priming Capabilities: 1.8m Suction Lift
- Inlet/Outlet Ports: 3/8" Hose Barb
- Weight: 0.57 kg
APPLICATIONS
Caravan, RV & Boat pressurised water systems
Sprayer fixtures (vehicle-mounted sprayers, electric sprayers)
Cleaning machines, humidifiers, water purification systems, medical apparatus
Solar water systems
Other pressurised systems
